Fragment-And-Replicate Technique

The fragment-and-replicate (f-a-r) strategy partitions only one relation and replicates the other for joining it with each fragment:

(8)

This method is particularly useful if R is huge and Q is small. This is a situation that occurs in what is frequently referred to as a star-join   [Red Brick Systems, 1995b]. An advantage is that there are no constraints on the R_k. Any partition of R into subsets will suit, especially a partition of R that might reside on the disks in the case of a parallel I/O system. This also means that this technique need not be affected by data skew . For this reason, load balancing  is fairly easy to achieve.

The major drawback, however, is that Q is required to be small in order to keep replication  costs marginal. If this is not the case then shipping Q over the interconnect of the parallel hardware can become the major bottleneck.

Depending on the join algorithm that is employed for processing the partial joins we get various search patterns. Figures 3.17 and 3.18 show the ones that arise when using a nested-loop and a sort-merge join respectively.



Figure: Search strategy of the fragment-and-replicate technique with the partial joins performed as nested-loops.



Figure: Search strategy of the fragment-and-replicate technique with the partial joins performed as sort-merge.
